| Parameter Configuration Table |
| Vehicle size: |
2780*980*1780mm |
Braking method: |
rear drum brake |
| Wheelbase: |
2100mm |
Maximum load: |
≤500KG |
| Ground clearance: |
300mm |
Rated number of passengers : |
5-people(including the driver) |
| Maximum speed (Km/H): |
≤40km/h |
Front/Rear Wheel Specifications: |
350 12 (non-tubeless) |
| Cruising range: |
100- 120km |
Battery Type: |
48V100AH Lead-acid batteries
Maximum battery size (420*180*280) |
| Climbing ability: |
≤20 degrees |
Battery Quantity: |
4 pieces (5 pieces are optional) |
| Minimum turning radius: |
3 meters |
charger: |
Input 220V50HZ;output48V, 15~20A(Pay attention to the plug specifications of the destination country) |
| Braking distance: |
3.2 meters |
Charging time: |
6-10 hours |
| Accessories Parameter List |
| front shock absorber |
43 hydraulic shock absorbers,Height 740 |
motor |
Brushless DC motor48V (optional 60V)900W,waterproof plug |
| Front drum brake |
|
rear axle |
differential gearOne large package of 160 rounds of pots,Drum brake |
| front honking horn |
Plastic cover with single speaker |
leaf spring |
5 piecesSmall curly ears |
| LCD instrument |
Electroplated bright circle |
With rear damping spring |
|
| Turn the handle |
|
steel wheel |
400-12 |
| LED headlight |
new style,non-round headlights |
tire |
350-12 |
| Turn signals and tail lights |
LED round turn signals and tail lights |
iron roof |
|
| dome light |
|
rain curtain |
Full car rain curtain |
| Rear view mirror with night light |
|
Canvas spare wheel cover |
painted |
| bluetooth radio |
Equipped with dual speakers |
seat back |
Ordinary painting |
| Wiper |
|
With front and rear pads |
Ordinary painting |
| anti-theft device |
4+2 with reverse |
glass frame |
Fan-shaped tube glass frame |
| controller |
48/60V45A24 tubes |
reflector |
seat type |
·It has an excellent load capacity and can easily carry 5 people (including the driver). It can not only be used for family travel, but also for carrying passengers in tourist cities. And we thoughtfully equipped armrests in the rear seats to ensure the safety of rear passengers. This electric passenger tricycle has a wide range of application scenarios.
·It has a strong battery life. This electric passenger tricycle is equipped with a 100Ah battery (can be upgraded to a larger capacity battery). High-capacity battery life, can travel 100-120km. When driving for long periods of time, you don't have to worry about running out of battery.
·This model is electric and complies with the low-carbon travel promoted by various governments. Low noise and low energy consumption bring you a more comfortable and energy-saving driving experience. In addition, the operation of this car is simple, and the driver can easily get started without special skills.
Pack photos
Our samples are shipped in the form of wooden boxes. If you are buying a electric tricycle cargo in a container, we have two models, one is half loose and the other is full loose.
Certificate
It have CE, ISO9001 certificates, etc.
Our Factory
Our Exhibition
Buyer show
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 7 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How do you make our business long-term and good relationship?
1. We maintain good quality and competitive prices to ensure profitability for our customers;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
